Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: XUAN CAI
  • Model Number: MLD-N1664RGB-T
  • Usage: Indoor
  • Tube Chip Color: Full Color
  • Display Function: Graphics
  • Pixels: 4.75mm
  • Screen Dimension: 3X12inch
  • outer frame: fireproof ABS +SMD3535
  • usage: indoor or semioutdoor
  • pixel: 4.75
  • communicate mode: USB computer or bluetooth addable
  • frame color: silver or black
  • control: PC software or IR remote controller or Bluetooth
  • install way: desktop or window mounted
  • display size: 335X105X20MM
  • Certificate: CE RoHS UL Certifications
  • warranty time: 1 year

Packaging & Delivery

Packaging Details Standard export carton and color box inside plastic Bag
Package: 20 pcs /carton
Inner box size: 32*9*10cm 0.6kg/ box
Carton size: 45*45*34cm
G.W : 12kg/ CTN.
Delivery Time samples:7-15 working days , usual order is 15~20 working days







Single color LED table deskop display message scrolling  display panel



Product Description

PH4.75mm
resolution8*48
display dimension1.6"(H)×8.3" (L) (40.6*210.8mm)
frame dimension10"(W) ×3"(H) ×0.8"(D) (254*76.2*20.3mm)
matirial ABS fireproof
power supply Max 12V 1000mA (DC socket)/ 5V (USB) 1000mA
rechargeable battery addable 2100mA

Function



A. European Characters: like English, Russian etc. and some symbols.
B. Brake signal: all LEDs keep lighting for 3 seconds when brake action is effective, then

show ‘STOP’
C. 26 messages(A-Z for remote control)/ software with 26 messages(A-Z). Each msg with

250 characters.
D. 6 stages of speed ,6 stages of brightness, 11 kinds of moving mode
E. Password protection
F. 12V cigarette lighter or 5V USB power supply (optional)
G. Message update: IR remote or PC (optional)





Packing photo









Packing info.



Size :  44.5*45*34  cm

QTY :  20pcs/ carton

G.W : 12 K.G





Certifications



Company Information

ShenZhen XuanCai Optoelectronics Co.,Ltd Was founded in 2010.



       As one of the leading asscociated member of Shenzhen professional manufacturer of led display screen products in China.Title honor of  ISO: 9001 &ISO:14001 &Shenzhen Top New 100 technology medium enterprises.

       We own powerful research and developing team which has more than 15 years experience in this LED sign software hardware feature and structure design etc.



Our advantageous:

     Advanced high precision mechnical equipment professional software and hardware engineers and strict production quality control system support us to research and supply worldwide level high quality featured and humanized products.



Our principles:

1>Leadship creation and responsibility are the first to the team.

2>Quality assurance and advanced design.

3>sincerely freindship cooperation relationship with each one customer.

4>Enviromental sustainability



other hotselling



Factory one cornor



Our Services

* 24 hours promt reply and manufacturer directly accept customized size.

*Perfect image ,design,packing and good quality and high cost performance.

*Provide nice pre-sale after-sale service and fast delivery.



Specific:



  • No limitation on Pixel;
  • No limitation on Pixel Pitch;
  • No limitation on Size;
  • No limitation on color;
  • No limitation on Communication way;
  • No limitation on Using place,not only the car nor the shop;
  • No limitation on packing methods,etc.

All are up to you only we can do!!!Showy!cool! Elegant! Good price*fast delivery*professional service .



Kindly pls confirm the quotation are based on the following factors.

  1. -Products size < screen size or frame size>
  2. -Pixel pitch:PH3/4/5/6/7.62/8/9/10/20/25...
  3. -Color: Monochrome/dual color /tri-color/full color
  4. -Application: (indoor nonwaterproof or outdoor waterproof or semi-outdoor rainproof)
  5. -Communication mode:(USB/RS232/keyboard/remote controller/WIFI/RF/GPRS..)
  6. -Display content. text,number,symbol,image,carton,animation.)
  7. -What languages.
  8. -Power.Voltage.
  9. -Installing way(desktop,hanging,standing,mounting..)
